Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale

Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale
Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale
Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale

Large Image :  Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale

Product Details:
Place of Origin: China
Brand Name: JH Fence
Certification: SGS
Model Number: Customization
Document: Cattle Fence Catalog from J... 1.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 2200-2500$
Packaging Details: Plastic wrap or wooden box
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 200 units a month
Contact Now

Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale

Description
Product Name: Hydralic Cattle Crushes Keyword: Cattle Crush
Pressure Treated Wood Type: Heat-treated Rail Size: 32mm OD,42mm OD,30X60mm &40x80mm Oval Rail Tube
Thickness: 2.0mm Type: Fencing
Frame: 32mm,40mm,42mm Round Tube,40x40mm & 50x50mm Square Tube Advantage: Long Service Life
Application: Livestock Farms Packing: Wooden Box
Highlight:

hydraulic cattle crush with weighing scale

,

heavy duty automatic cattle squeeze

,

manual cattle crush for weighing

Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale
Cattle Crushes  Introduction

Cattle have to be constrained during routine operations, such as recording, vaccinating, ear tagging, weighing and animal health tasks (and possibly veterinary procedures). A cattle crush holds the animal immobilized to minimize the risk of injury to both the animal and the handler. 2.5m Height 3.5m Width Cattle Crush Set Ranches And Farms


Cattle Crushes Product Specifications
Attribute Value
Product name Hydralic Cattle Crush
Weight 1150kgs
Pressure treated wood type Heat-treated
Rail size 32mm OD,42mm OD,30X60mm &40x80mm oval rail tube
Thickness 2.0mm
Type Fencing
Frame 32mm,40mm,42mm round tube,40x40mm & 50x50mm square tube
Color  Blue,Green,Red
Application Livestock Markets
Packing Wooden Case
Cattle Crushes Set Dimensions
Size 3500X1450X2500mm
Oval Rail 40*80mm*1.6mm 42*115mm*1.6mm
Material Hot-dip galvanized steel tube
Welded Fully welded post brackets
Customization Other size as customer requirement
Cattle Crushes Key Features
  • Fully opening walk thru head bail
  • Auto lock sliding gate
  • Onside or offside effortless operation available
  • High carbon steel Q235 material welding
  • 50X50 frame construction
  • Vet Facilities front and rear
  • Length: 3500mm
  • Width: 1400mm
  • Height: 2500mm
  • Cattle crush is composed of sliding gate, cattle headbale, veterinary area, side door inspection area and anti-kick area
Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale 0 Hydraulic Heavy Duty Automatic Manual Cattle Squeeze Cattle Crush with Weighing Scale 1
Manufacturer Information

Anping JiaHui wire mesh Co., LTD is based on One-stop Solution of fence project, including farm fence, temporary fence, steel fence, welded wire mesh, chain Link fence, and barbed wire.

Our factory is located in Anping, China. With more than 20 years of experience in producing wire mesh products and export.

We have professional producing team and equipment, high efficiency sales team and competitive price superiority. We are able to undertake large-scale projects.

We export a large quantity of wire mesh fence to Australia, America, Russia, Middle East, Europe and Africa.
